Scott Scale RC 400

Scott Scale RC 400
Color: Alloy
Size: 24-inch
Please select options Unavailable


The SCOTT Scale RC 400 is a capable, do-it-all mountain bike for kids. The compact frame, paired with 24" inch wheels and custom kid components, gives kids stability and smooth rolling to conquer whatever they come across on the trail.

Key Features:
- JR24 Rigid Disc Light Alloy Frame
- Rigid Fork / IS
- Shimano Deore, 11 Speed
- Shimano Hydraulic Disc Brakes
- Schwalbe Rocket Ron Tires

A Head Tube Angle 69°
B Head Tube Length 120mm
C Top Tube Horizontal 500mm
D Standover Height 590mm
E BB Offset -45mm
F BB Height -45mm
G Wheel Base 971mm
H BB Center To Toptube Center 220mm
I BB Center To Top Of Seattube 275mm
J Seat Angle 73.5°
K Chainstay 400mm
L Reach 353mm
M Stack 493mm


Frame JR24 Rigid Disc light Alloy 6061 / Bent TT / Semi-integrated headtube / SCOTT dropout / IS
Fork AL-6061 rigid fork / 1 1/8" / IS
Rims Alexrims MD19 / Disc
Hubs Front: Formula DC-140-F / QR
Rear: Formula DC-38-R / QR
Spokes 15g / UCP / black
Tires Schwalbe Rocket Ron Evolution / ADDIX Speed 67EPI / 24x2.25" / folding
Bottom Bracket Feimin / BB68 / cartridge / square taper
Crankset Prowheel BOOM-32P / 140MM 32T Alloy / w/CG PVC single cover
Shifters Shimano Deore SL-M5100-R / 11-Speed
Rear Derailleur Shimano Deore RD-M5100
Cassette/Freewheel SunRace CSMX8 11 Speed / 11-42T
Chain KMC X11EL
Brakes Shimano BR-MT500
Rotors Shimano SM-RT66 / IS / 160mm
Brake Levers Shimano BL-MT501
Handlebars Premetec 6019F / Flat Bar / 25.4mm clamp / 580mm / Syncros Youth 100 Grip
Stem LEADTEC LCS-7091 50mm / 25.4mm clamp
Headset Feimin FP-H809, sealed bearings
Seatpost Alloy 2014 / 0mm Offset / 27.2x300mm
Saddle Syncros Future Pro
Pedals MARWI SP-700 / w/Reflector

* Subject to change without notice.

Part Numbers

Option UPC MPN Store SKU
Alloy / 24-inch 192820613994 286609222 SCO24341373E
