Scott Ransom 600
This item is currently not available.
Details
The SCOTT Ransom 600 is the fast and capable mountain bike for kids that dreams are made of. With 26" inch wheels, a kid-tuned long travel fork (140mm) and shock (130mm) in combination with a flip chip, the Ransom can grow (or shrink) to run 24" or 26" inch wheels. The Future Pro Ransom: Never Too Young.
Key Features:
- Ransom 24"/26" Alloy 6061
- X-Fusion Slant RC 26 / 140mm
- X-Fusion R / Kids Bike Tune
- Shimano Deore, 11 Speed
- Shimano Disc Brakes
- Syncros DP30 Rims
- Kenda Hellkat Tires
- Syncros Parts
| Wheel Size | 24" | 26" |
|---|---|---|
| BB Setting | HIGH | LOW |
| A. Reach | 366.8 mm | 360.0 mm |
| B. Stack | 553.6 mm | 558.1 mm |
| C. Standover | 597.9 mm | 621.5 mm |
| D. Effective Top Tube | 497.7 mm | 499.1 mm |
| E. Head Tube Angle | 65.7 ° | 65.0 ° |
| F. Head Tube Length | 90.0 mm | 90.0 mm |
| G. Seat Tube Angle | 76.7 ° | 76.0 ° |
| H. Seat Tube Length | 320.0 mm | 320.0 mm |
| I. Bottom Bracket Height | 305.0 mm | 325.0 mm |
| J. Bottom Bracket Drop | -13.0 mm | -21.0 mm |
| L. Trail | 98.6 mm | 116.1 mm |
| M. Wheelbase | 1,078.3 mm | 1,080.2 mm |
| O. Chainstay Length | 422.6 mm | 425.0 mm |
| Stem Length | 40.0 mm | 50.0 mm |
Specs
| Frame | Ransom 24"/26" Alloy 6061 Custom Butted Tubing / Tapered Headtube / BB73 / Internal cable routing / UDH 148x12mm |
|---|---|
| Fork | X-Fusion Slant RC 26 / 140mm / tapered / Kids Bike Tune |
| Rear Shock | X-Fusion 02Pro R Trunnion / Rebound Adjuster / Kids Bike Tune / Travel 130mm / 165x45mm |
| Rims | Syncros DP30 / 32H / 30mm |
| Hubs |
Front: Formula DC-71 IS / Boost 15x110mm Rear: Formula DC-3248 IS / Boost 12x148mm |
| Spokes | Stainless Black 15g / 1.8mm |
| Axles |
Front: 15x110mm Rear: 12x148mm |
| Tires | Kenda Hellkat K1201 / 60TPI / Folding / 26x2.4 |
| Bottom Bracket | Prowheel BB73 |
| Crankset | Prowheel CHARM-2P / Boost / 140mm |
| Chainrings | 32T |
| Shifters | Shimano Deore SL-M5100-R |
| Rear Derailleur | Shimano Deore RD-M5100 11-Speed |
| Cassette/Freewheel | Shimano CS-M5100-11 / 11-51T |
| Chain | KMC X11 |
| Brakes | Shimano BR-MT500 |
| Rotors | Shimano Deore SM-RT56 / IS / F: 180 R: 160 |
| Brake Levers | Shimano BL-MT501 |
| Handlebars | Syncros T-Bar / Alloy 6061 / T Shape Flat / 9° / 640mm / Syncros Youth 115 |
| Stem | Syncros 6061 Alloy / Oversized 31.8mm / 1 1/8" / 7° angle |
| Headset | Syncros OE Press Fit / Reduce 1.5"-1 1/8" / OD 50/62mm / ID 44/56mm |
| Seatpost | Syncros Dropper Ducan Remote / 31.6mm / 80mm / Kid Centric Custom Tune |
| Saddle | Syncros Future Pro |
| Pedals | Wellgo J345 w/ Reflector |
* Subject to change without notice.
