Details
The SCOTT Ransom 400 is the fast and capable mountain bike for kids that dreams are made of. With 24" inch wheels, a kid-tuned long travel fork (140mm) and shock (130mm) in combination with a flip chip, the Ransom can grow (or shrink) to run 24" or 26" inch wheels. The Future Pro Ransom: Never Too Young.
Key Features:
- Ransom 24"/26" Alloy 6061
- X-Fusion Slant RC 26 / 140mm Fork
- X-Fusion R / Kids Bike Tune
- Shimano Deore, 11-Speed
- Shimano Disc Brakes
- Syncros DP30 Rims
- Kenda Hellkat Tires
- Syncros Parts
Wheel Size | 24" | 26" |
---|---|---|
BB Setting | HIGH | LOW |
A. Reach | 366.8 mm | 360.0 mm |
B. Stack | 553.6 mm | 558.1 mm |
C. Standover | 597.9 mm | 621.5 mm |
D. Effective Top Tube | 497.7 mm | 499.1 mm |
E. Head Tube Angle | 65.7 ° | 65.0 ° |
F. Head Tube Length | 90.0 mm | 90.0 mm |
G. Seat Tube Angle | 76.7 ° | 76.0 ° |
H. Seat Tube Length | 320.0 mm | 320.0 mm |
I. Bottom Bracket Height | 305.0 mm | 325.0 mm |
J. Bottom Bracket Drop | -13.0 mm | -21.0 mm |
L. Trail | 98.6 mm | 116.1 mm |
M. Wheelbase | 1,078.3 mm | 1,080.2 mm |
O. Chainstay Length | 422.6 mm | 425.0 mm |
Stem Length | 40.0 mm | 50.0 mm |
Specs
Frame | Ransom 24"/26" Alloy 6061 Custom Butted Tubing / Tapered Headtube / BB73 / Internal Cable Routing / UDH 148x12mm |
---|---|
Fork | X-Fusion Slant RC 26 / 140mm / Tapered / Kids Bike Tune |
Rear Shock | X-Fusion 02Pro R Trunnion / Rebound Adjuster / Kids Bike Tune / Travel 130mm / 165x45mm |
Rims | Syncros DP30 / 32H / 30mm |
Hubs |
Front: Formula DC-71 IS / 15x110mm Rear: Formula DC-3248 IS / Boost 12x148mm |
Spokes | Stainless Black 15g / 1.8mm |
Axles |
Front: 15x110mm Rear: 12x148mm |
Tires | Kenda Hellkat K1201 / 60TPI / Folding / 24x2.4 |
Bottom Bracket | Prowheel BB73 |
Crankset | Prowheel CHARM-2PC / Boost / 127mm |
Chainrings | 32T |
Shifters | Shimano Deore SL-M5100-R |
Rear Derailleur | Shimano Deore RD-M5100 11-Speed |
Cassette/Freewheel | Shimano CS-M5100-11 / 11-51 |
Chain | KMC X11 |
Brakes | Shimano BR-MT500 |
Rotors | Shimano Deore SM-RT56 / IS / F: 180 R: 160 |
Brake Levers | Shimano BL-MT501 |
Handlebars | Syncros T-Bar / Alloy 6061 / T Shape Flat / 9° / 600mm / Syncros Youth 115 |
Stem | Syncros 6061 Alloy / Oversized 31.8mm / 1 1/8" / 7° angle |
Headset | Syncros OE Press Fit / Reduce 1.5"-1 1/8" / OD 50/62mm / ID 44/56mm |
Seatpost | Syncros Dropper Ducan Remote / 31.6mm / 80mm / Kid Centric Custom Tune |
Saddle | Syncros Future Pro |
Pedals | Wellgo J345 w/ Reflector |
* Subject to change without notice.
Part Numbers
Option | UPC | MPN | Store SKU |
---|---|---|---|
Dark Green / 24-inch | 192820613895 | 286604222 | SCO23302084E |
